₱8,900.00
Wall Mount Speaker The TNi-W8 delivers professional audio output and versatility within a compact, wall-mount speaker enclosure. The TNi-W8 – 8 inch passive speaker - features 4 power tappings ranging from 2.5W - 40W and can be connected to 70V/1...
Availability: 2-3 Days
- Brand: HH Electronics
Wall Mount Speaker
The TNi-W8 delivers professional audio output and versatility within a compact, wall-mount speaker enclosure. The TNi-W8 – 8 inch passive speaker - features 4 power tappings ranging from 2.5W - 40W and can be connected to 70V/100V or 8 ohm low impedance lines. Equipped with euroblock and M4 screw terminals, The TNi-W8 offers a wide array of connections within a single unit.
With solid steel, multi-angle bracket included, The TNi-W8 comes with all essential installation components.
| Specifications | |
|---|---|
| Model: | TNi-W8 |
| System Type: | Passive, 2-way, Bass Reflex |
| Woofer Size: | 8" |
| Tweeter Size: | 1" Dome Tweeter |
| 100V Power Options: | 40W, 20W, 10W, 5W |
| 70V Power Options: | 20W, 10W, 5W, 2.5W |
| Low Nominal System Impedance: | 8 ohm |
| Power Rating: | 65W AES, 260W Peak |
| Recommended Amplifier | 100-200W @ 8 Ohms |
| Sensitivity 1W/1m | 91 dB SPL |
| Maximum SPL (1m) | 115 dB SPL |
| Frequency response | 55Hz - 20KHz (-10dB) |
| 75Hz - 18KHz (-3dB) | |
| Input / Link Connector | Euroblock and M4 terminals |
| Horizontal Dispersion Angle | 90° |
| Vertical Dispersion Angle | 80° |
| Enclosure | |
|---|---|
| Main Construction Material: | ABS Plastic |
| Finish: | Black (White finish optional, subject to MOQ) |
| Grille: | Black, Circular Steel Mesh |
| Mounting Bracket: | Adjustable Steel Bracket include |
| Shipping Spec | |
|---|---|
| Unit dimensions (HWD): | 390 x 240 x 319mm, 15.4" x 9.4" x 12.6" |
| Unit weight: | 4.2Kg, 9.3 lbs |
| Single Carton dimensions (HWD): | 515 x 280 x 270mm, 20.3" x 11" x 10.6", 0.039m³ |
| Packed weight: | 5Kg, 11 lbs |
| Master Carton dimensions (HWD): | 530 x 595 x 575mm, (20.9" x 23.4" x 22.6") (4pcs) |
| Master Packed weight: | 21.3Kg, 47 lbs |
