₱3,900.00
The Tessen TNi-C4 delivers premium audio reinforcement. Designed with the installer in mind, The TNi-C4 – 4 inch coaxial ceiling speaker - features a 6 position power tap selector located under the front steel grille, providing swift output adjustm...
Availability: 2-3 Days
- Brand: HH Electronics
The Tessen TNi-C4 delivers premium audio reinforcement. Designed with the installer in mind, The TNi-C4 – 4 inch coaxial ceiling speaker - features a 6 position power tap selector located under the front steel grille, providing swift output adjustment once installed.
With connectivity for 70V/100V and 8 ohm low impedance lines, The TNi-C4 delivers a highly flexible solution. The spring connection terminals ensure cables are secure once fitted.
| SPECIFICATIONS | |
|---|---|
| 100V Power Options | 30W, 15W, 6W |
| 70V Power Options | 15W, 7.5W, 3W |
| Frequency Response (-10) | 85Hz - 20KHz |
| Frequency Response (-3) | 100Hz - 16KHz |
| LF Driver | 4 Inch, Paper Cone |
| HF Driver | 1.5 inch Neodymium |
| Low Nominal System Impedance | 8 OHM |
| Power | 45W AES, 180W Peak |
| Max SPL (1M) (Peak) | 111 dB |
| Sensitivity (1W/1M) | 88 DB SPL |
| Recommended Amplifier | 80-160W @ 8 Ohms |
| Nominal Coverage | 130° conical |
| Input Connector | PUSH SPRING CONNECTORS |
| Mounting Points | 3X DOG EAR BRACKETS |
| Mounting Depth | 156mm, 6.1 Inches |
| Installation Grip Range | 4 - 20mm |
| Cutout | 180mm, 7.1 Inches |
| Outside Diameter | 204mm, 8 Inches |
| Unit Weight | 1.4KG, 3.1 LBS |
| Main Construction Material | ABS PLASTIC |
| Grille | 1.5MM CIRCULAR MESH STEEL |
| Finish | WHITE |
